| Model | DHG1T | DHG1.5T | DHG2-01 | DHG2-02 | DHG2.5 | DHG3-01 | DHG3-02 | DHG3-03 | DHG5 | |
| Rated Load | Ton | 1.00 | 1.50 | 2.00 | 2.00 | 2.50 | 3.00 | 3.00 | 3.00 | 5.00 |
| Power | kw | 1.50 | 3.00 | 3.00 | 1.50 | 3.00 | 3.00 | 3.00 | 1.50 | 3.00 |
| Voltage | V | 380V | 380V | 380V | 380V | 380V | 380V | 380V | 380V | 380V |
| Lifting Speed m/min | m/min | 6.60 | 8.80 | 6.60 | 6.60 | 5.40 | 5.40 | 4.40 | 2.20 | 2.70 |
| Rotation Speed | r/min | 1440.00 | 1440.00 | 1440.00 | 1440.00 | 1440.00 | 1440.00 | 1440.00 | 1440.00 | 1440.00 |
| Phases | 3.00 | 3.00 | 3.00 | 3.00 | 3.00 | 3.00 | 3.00 | 3.00 | 3.00 | |
| Fequency | Hz/s | 50.00 | 50.00 | 50.00 | 50.00 | 50.00 | 50.00 | 50.00 | 50.00 | 50.00 |
