| Art No. | Rated Pull | Gbap Ratlo | Handle Length | Drum-Hub Diameter | Cable Size | Weight | |
| Diameter | Length | ||||||
| lbs（kgs) | mm | mm | mm | m | kg/pc | ||
| WH02-0600 | 600(270) | 3.1:1 | 165 | 16 | 4.2 | 8 | 2.17 |
| WH02-0800 | 800(360) | 3.1:1 | 175 | 16 | 4.2 | 8 | 2.5 |
| WH02-1000 | 1000(450) | 4.1:1 | 200 | 18 | 4.2 | 10 | 3.08 |
| WH02-1200 | 1200(540) | 4.1:1 | 225 | 18 | 4.2 | 10 | 3.33 |
| WH02-1400 | 1400(630) | 4.5:1 | 225 | 18 | 4.5 | 10 | 3.25 |
| WH02-1600 | 1600(720) | 5.1:1 | 225 | 20 | 4.5 | 10 | 4.12 |
| WH02-1800 | 1800(810) | 4.1:1&9.8:1 | 250 | 20 | 5.0 | 10 | 4.87 |
| WH02-2000 | 2000(900) | 4.1:1&9.8:1 | 250 | 20 | 5.0 | 10 | 5.13 |
| WH02-2500 | 2500(1100) | 5.1:1&12.2:1 | 275 | 42 | 5.0 | 10 | 5.38 |
| WH02-3000 | 3000(1350) | 5.1:1&12.2:1 | 290 | 42 | 5.0 | 10 | 5.75 |
