| Art No. | WLL | Sheave Dia | Hook | Eye | Wire Rope | Weight | ||
| Ton | D mm | A1 mm | A2 mm | B mm | C1 mm | mm | kg/pc | |
| BL12-075 | 0.50 | 75.00 | 268.00 | 227.00 | 87.00 | 50.00 | 8.00 | 1.50 |
| BL12-100 | 1.00 | 100.00 | 311.50 | 284.50 | 112.00 | 55.50 | 10.00 | 2.60 |
| BL12-125 | 1.50 | 125.00 | 370.00 | 344.00 | 140.00 | 63.50 | 13.00 | 4.80 |
| BL12-150 | 2.00 | 150.00 | 442.50 | 417.00 | 168.00 | 101.00 | 16.00 | 7.40 |
| BL12-180 | 3.00 | 180.00 | 498.00 | 478.00 | 204.00 | 107.00 | 19.00 | 11.90 |
| BL12-200 | 4.00 | 200.00 | 590.50 | 556.00 | 226.00 | 128.00 | 22.00 | 20.40 |
| BL12-250 | 5.00 | 250.00 | 706.50 | 651.00 | 276.00 | 147.00 | 25.00 | 33.00 |
| BL12-300 | 6.00 | 300.00 | 795.00 | 775.00 | 330.00 | 162.00 | 26.00 | 48.00 |
| BL12-350 | 10.00 | 350.00 | 934.00 | 898.00 | 395.00 | 178.00 | 28.00 | 66.00 |
