| Art No. | WLL | Sheave Dia | Shackle | Hook | Wire Rope | Weight | ||
| Ton | mm | A1 mm | A2 mm | B mm | C mm | mm | kg/pc | |
| BL01-02/075 | 2.00 | 75.00 | 286.00 | 292.00 | 82.00 | 70.00 | 7-9 | 4.00 |
| BL01-04/115 | 4.00 | 115.00 | 345.00 | 358.00 | 120.00 | 70.00 | 10-12 | 6.10 |
| BL01-04/150 | 4.00 | 150.00 | 399.00 | 412.00 | 160.00 | 70.00 | 16-18 | 13.80 |
| BL01-08/150 | 8.00 | 150.00 | 475.00 | 498.00 | 160.00 | 93.00 | 20-22 | 14.40 |
| BL01-08/200 | 8.00 | 200.00 | 528.00 | 549.00 | 210.00 | 93.00 | 20-22 | 16.00 |
| BL01-15/200 | 15.00 | 200.00 | 663.00 | 672.00 | 230.00 | 102.00 | 22-24 | 24.00 |
| BL01-10/250 | 10.00 | 250.00 | 679.00 | 695.00 | 260.00 | 115.00 | 24-26 | 37.50 |
| BL01-12/250 | 12.00 | 250.00 | 679.00 | 701.00 | 260.00 | 115.00 | 24-26 | 42.00 |
| BL01-12/300 | 12.00 | 300.00 | 767.00 | 797.00 | 310.00 | 133.00 | 28-32 | 56.00 |
| BL01-15/300 | 15.00 | 300.00 | 952.00 | 797.00 | 365.00 | 140.00 | 28-32 | 65.00 |
| BL01-22/355 | 22.00 | 355.00 | 952.00 | 960.00 | 365.00 | 140.00 | 32-35 | 90.00 |
| BL01-22/400 | 22.00 | 400.00 | 1019.00 | 1027.00 | 415.00 | 140.00 | 32-35 | 108.00 |
| BL01-30/400 | 30.00 | 400.00 | 1126.00 | 1085.00 | 415.00 | 155.00 | 32-35 | 135.00 |
| BL01-30/500 | 30.00 | 500.00 | 1256.00 | 1177.00 | 514.00 | 162.00 | 32-35 | 210.00 |
