| Art No. | Trade Size | Wire Diameter | Length Per 100Links | Working Load Limit | Working Load Limit | Breaking Test Load | Breaking Test Load | Weight/100ft | Weight/100ft |
| inches | inches | pounds-steel | pounds-brass | pounds-steel | pounds-brass | pounds-steel | pounds-brass | ||
| CH29-0.047 | 10 | 0.047 | 39 | 5 | 4 | 20 | 15 | 1.75 | 1.90 |
| CH29-0.062 | 16 | 0.062 | 52 | 10 | 8 | 40 | 30 | 3.00 | 3.25 |
| CH29-0.080 | 14 | 0.080 | 63 | 16 | 11 | 65 | 45 | 5.00 | 5.40 |
| CH29-0.105 | 12 | 0.105 | 75 | 29 | 20 | 115 | 80 | 8.50 | 9.15 |
| CH29-0.135 | 10 | 0.135 | 95 | 43 | 34 | 170 | 135 | 14.70 | 15.80 |
| CH29-0.132 | 8 | 0.132 | 109 | 60 | 43 | 240 | 170 | 20.50 | 22.00 |
| CH29-0.192 | 6 | 0.192 | 122 | 58 | 66 | 350 | 285 | 28.50 | 30.70 |
