| Art No. | Diameter (inch) | Breaking Strength(lb) | Weight | ||||||
| Inner Cable | Outer Cover | Inner Cable | PVC Coating | Total | |||||
| lb/1000ft | kg/1000ft | lb/1000ft | kg/1000ft | lb/1000ft | kg/1000ft | ||||
| WP12-3/32-1/8 | 3/32" | 1/8" | 1,000 | 17.4 | 7.89 | 3.2 | 1.44 | 20.6 | 9.33 |
| WP12-3/32-5/32 | 3/32" | 5/32" | 1,000 | 17.4 | 7.89 | 7.2 | 3.26 | 24.6 | 11.15 |
| WP12-1/8-5/32 | 1/8" | 5/32" | 2,000 | 29.0 | 13.15 | 4.1 | 1.84 | 33.1 | 14.99 |
| WP12-1/8-3/16 | 1/8" | 3/16" | 2,000 | 29.0 | 13.15 | 9.0 | 4.06 | 38.0 | 17.21 |
| WP12-5/32-7/32 | 5/32" | 7/32 | 2,800 | 45.0 | 20.41 | 10.8 | 4.90 | 55.8 | 25.31 |
| WP12-5/32-9/32 | 5/32" | 9/32 | 2,800 | 45.0 | 20.41 | 25.1 | 11.40 | 70.1 | 31.81 |
| WP12-3/16-1/4 | 3/16" | 1/4" | 4,200 | 65.0 | 29.48 | 12.6 | 5.70 | 77.6 | 35.18 |
| WP12-3/16-5/16 | 3/16" | 5/16" | 4,200 | 65.0 | 29.48 | 28.8 | 13.05 | 93.8 | 42.53 |
| WP12-1/4-5/16 | 1/4" | 5/16" | 7,000 | 110.0 | 49.90 | 16.2 | 7.33 | 126.2 | 57.23 |
| WP12-1/4-3/8 | 1/4" | 3/8" | 7,000 | 110.0 | 49.90 | 35.9 | 16.30 | 145.9 | 66.20 |
| WP12-5/16-3/8 | 5/16" | 3/8" | 9,800 | 173.0 | 78.47 | 19.8 | 8.96 | 192.8 | 87.43 |
| WP12-5/16-7/16 | 5/16" | 7/16" | 9,800 | 173.0 | 78.47 | 43.1 | 19.55 | 216.1 | 98.02 |
| WP12-3/8-7/16 | 3/8" | 7/16" | 14,400 | 243.0 | 110.22 | 23.3 | 10.60 | 266.3 | 120.82 |
| WP12-3/8-1/2 | 3/8" | 1/2" | 14,400 | 243.0 | 110.22 | 50.3 | 22.80 | 293.3 | 133.02 |
