| Art No. | Diameter (inch) | Breaking Strength(lb) | Weight | ||||||
| Inner Cable | Outer Cover | Inner Cable | PVC Coating | Total | |||||
| lb/1000ft | kg/1000ft | lb/1000ft | kg/1000ft | lb/1000ft | kg/1000ft | ||||
| WP11-3/64-1/16 | 3/64" | 1/16" | 270 | 4.2 | 1.91 | 0.8 | 0.36 | 5.0 | 2.27 |
| WP11-3/64-5/64 | 3/64" | 5/64" | 270 | 4.2 | 1.91 | 1.8 | 0.81 | 6.0 | 2.72 |
| WP11-1/16-3/32 | 1/16" | 3/32" | 480 | 7.5 | 3.40 | 2.2 | 1.02 | 9.7 | 4.42 |
| WP11-1/16-1/8 | 1/16" | 1/8" | 480 | 7.5 | 3.40 | 5.4 | 2.45 | 12.9 | 5.85 |
| WP11-3/32-1/8 | 3/32" | 1/8" | 920 | 16.0 | 7.26 | 3.1 | 1.43 | 19.1 | 8.69 |
| WP11-3/32-5/32 | 3/32" | 5/32" | 920 | 16.0 | 7.26 | 7.2 | 3.26 | 23.2 | 10.52 |
| WP11-1/8-5/32 | 1/8" | 5/32" | 1,700 | 28.5 | 12.93 | 4.1 | 1.84 | 32.6 | 4.70 |
| WP11-1/8-3/16 | 1/8" | 3/16" | 1,700 | 28.5 | 12.93 | 9.0 | 4.06 | 37.5 | 16.99 |
| WP11-3/16-1/4 | 3/16" | 1/4" | 3,700 | 62.0 | 28.12 | 12.6 | 5.70 | 74.6 | 33.82 |
| WP11-1/16-5/16 | 1/16" | 5/16" | 3,700 | 62.0 | 28.12 | 28.8 | 13.05 | 90.8 | 41.17 |
